ACOG Mount w/ Q-LOC
The Trijicon ACOG® Extra High Mount with Trijicon Q-LOC™ Technology features a Mil-Spec drop test rated 6061-T6 aluminum design, with an easy to use one handed toolless mounting system. The spring-loaded design allows for constant retention and maintaining of zero even if the knobs are not tightened.
This mount boasts a low weight and low profile design with precise return to zero performance and is compatible with any Mil-Spec or NATO Picatinny rail.
Designed specifically for heads up shooting with the Trijicon ACOG®.
• Matte Black Anodized Finish
• Made in the USA
Distance From Top of Mounting Rail to Optical Axis:
2.05″
Torque Spec (to Rail):
Spring Tension Only: 12-16 in. / lbs
Can be Tightened To: 30-38 in. / lbs
Description:
- Quick-release, return to zero
- Automatic retention keeps optic secure
- Snag resistant knob design
- Precision cut dimensions
- Proven durability
Specifications:
- Housing Material 6061-T6 Aluminum
- Finish Matte Black
- Length 3.5 in (88.9mm)
- Width 2.4 in (60.96mm)
- Height Above Rail (in/mm) 2.05″ in. (52.07mm)
- Feature Trijicon Q-LOC™ Technology
